| Codes | YGWL30-AS | YGWL30-PS | YGWL30-MS | YGWL30-EM | YGWL30-EMPS | YGWL30-EMMS |
| Input Voltage | AC220-240V 50/60Hz | |||||
| Power Consumption (W): | 30W/26W/22W/18W | 30W/26W/22W/18W +EM 2W | ||||
| DF | >0.7 | |||||
| Ripple current | <10% | |||||
| LED | SMD 2835 | |||||
| Light output L100 (lm): | 3000/2600/2200/1800LM±10％ | |||||
| CCT L100 (K): | 3000/4000/6500K±300K | |||||
| CRI L100: | >80 | |||||
| Efficacy (lm/W): | 100LM/W | |||||
| Operate Levels (LX) | NA | 10~20Lx On (All types of light) 30~80Lx Off (natural light) | ADJ | NA | 10~20Lx On (All types of light) 30~80Lx Off (natural light) | ADJ |
| L×W×H (mm): | 306×265×110 | |||||
